R1
Product Code: R001
$180
- Two layers are designed (chamber) on the opposite side of the air hole module to avoid direct heat transfer to the outside.
- Eccentric design style to create more space for optimized ventilation.
- Good conductive due to not using the O-ring between deck and topcap and threaded connection from topcap to the chimney.
Overall
- Dimension (WxDxH): 15x13x40 mm.
- Air hole diameter: 2x0.8 mm, 2x1 mm, 2x1.2 mm.
Note: We only engrave 1 number on top of the air hole module for identification, for example 0.8 for 2x0.8 mm.
- Wick hole diameter: 3.5 mm.
- Space to place the coil: 6 mm.
- Height of the mesh wick: 9 mm.
Materials
- Body, Center post: SS-316.
- Air hole module: White Peek.
- Insulator: Peek.
- Black Oring: Black Peek (This part is able to change with different materials and colors in the future).
Manufacturing process
- CNC Milling.
Origin
- Vietnam
